導致全自動攪拌車發動機水溫高的6個原因
全自動攪拌車發動機系統是一個整體，需要每個部件緊密配合才能滿足發動機的工作需求；這些部件中只要有一個出現問題，都會影響發動機正常工作。發動機水溫的正常情況下應當是在80°C~90°C之間，如果水溫經常高于95°C或者開鍋就應該檢查故障了。那么是什么原因?qū)е铝怂疁剡^高呢？
The engine system of a fully automatic mixer truck is a whole, and each component needs to be closely coordinated to meet the working requirements of the engine; Any problem with one of these components will affect the normal operation of the engine. Under normal circumstances, the engine water temperature should be between 80 ° C and 90 ° C. If the water temperature often exceeds 95 ° C or the boiler is turned on, the fault should be checked. So what is the reason for the high water temperature?
日常保養要到位
Daily maintenance should be in place
水箱里的冷卻液低于低刻度線以下，這個就是日常保養工作不到位沒有注意到冷卻液的缺失。添加冷卻液規定刻度即可。
The coolant in the water tank is below the low mark, which is due to inadequate daily maintenance work and failure to pay attention to the lack of coolant. Add coolant to the specified scale.
留意保溫簾通風情況
Pay attention to the ventilation of the insulation curtain
水箱上安裝的散熱扇皮帶松緊度不夠，打滑導致風扇和水泵的轉速不夠，風扇轉速不夠?qū)е滤涞睦滹L流量太低，水泵的轉速不夠?qū)е吕鋮s液的循環速度太慢。在水箱前方裝有保溫簾的卡友，在水溫升高的時候沒有注意到打開保溫簾通風降溫。
The tightness of the cooling fan belt installed on the water tank is insufficient, causing slipping, resulting in insufficient speed of the fan and water pump. Insufficient fan speed leads to too low cold air flow rate in the water tank, and insufficient speed of the water pump leads to too slow circulation speed of the coolant. The card friend who is equipped with an insulation curtain in front of the water tank did not notice opening the insulation curtain for ventilation and cooling when the water temperature increased.
水箱水管堵塞
Blocked water pipe in water tank
全自動攪拌車廠家提醒，水箱水管堵塞導致水管截面變小，水循環效率降低，因為水箱散熱水管的堵塞，水管截面變小使發動機內進入水箱上水管的水量遠多于下水管進入發動機的水量。
The manufacturer of the fully automatic mixing truck reminds that the blockage of the water tank pipe leads to a smaller section of the water pipe and a decrease in water circulation efficiency. Due to the blockage of the radiator pipe in the water tank, the smaller section of the water pipe causes the amount of water entering the upper water pipe of the water tank in the engine to be much more than the amount entering the engine from the lower water pipe.
結果就是經冷卻過后的水都積壓在水箱的上水管，使上水管壓力增高，造成水箱泄水，泄水后水量減少致使發動機過熱。
The result is that the cooled water accumulates in the upper water pipe of the water tank, increasing the pressure of the upper water pipe and causing the water tank to leak. After the leak, the amount of water decreases, causing the engine to overheat.
節溫器是否失效
Is the thermostat ineffective
節溫器長期使用后出現故障或者功能衰減使閥門的開度變小，致使水循環緩慢甚中斷，進而導致發動機水溫過高。
After long-term use, the thermostat malfunctions or its function decays, causing the valve opening to decrease, resulting in slow or even interrupted water circulation, and ultimately leading to high engine water temperature.
判斷節溫器是否可以繼續使用的檢測標準為，把節溫器放在水里加熱檢查閥門開始開啟的溫度和完全開啟的溫度以及閥門從開啟完全開啟的升程。閥門開始開啟的溫度一般為80°C左右，完全開啟時的溫度一般為90°C左右，閥門工作的升程一般為7~10毫米。
The testing standard for determining whether the thermostat can continue to be used is to place it in water and heat it to check the temperature at which the valve starts to open and fully opens, as well as the lift of the valve from open to fully open. The temperature at which the valve starts to open is generally around 80 ° C, the temperature at which it fully opens is generally around 90 ° C, and the working lift of the valve is generally 7-10 millimeters.
水泵故障
Water pump malfunction
在寒冷天氣如果沒有添加防凍液，那么全自動攪拌車水泵里的水就容易結冰導致水泵葉輪不能轉動。啟動車輛時，皮帶強行帶動水泵轉動，就很容易造成水泵損壞。
If antifreeze is not added in cold weather, the water in the water pump of the fully automatic mixer truck is prone to freezing, causing the water pump impeller to not rotate. When starting the vehicle, the belt forcefully drives the water pump to rotate, which can easily cause damage to the water pump.
風扇離合器故障
Fan clutch failure
現在路上跑的卡車包括攪拌車等專用車大部分都配備有風扇離合器，風扇離合器可以根據發動機的溫度來調節風扇的轉速，使發動機持續在佳工作狀態下工作。當風扇離合器發生故障時，就容易引起水溫過高，水箱開鍋。
Most of the trucks running on the road now, including mixer trucks and other specialized vehicles, are equipped with a fan clutch. The fan clutch can adjust the fan speed according to the engine temperature, so that the engine can continue to work in good working condition. When the fan clutch malfunctions, it is easy to cause the water temperature to be too high and the water tank to boil.
導致全自動攪拌車發動機水溫高的6個原因就講解完畢了，希望能夠給您好的幫助，更多事項就來我們網站http://www.jbckj.cn咨詢吧！
The six reasons for the high engine water temperature of the fully automatic mixer truck have been explained. We hope to provide you with good help. For more information, please come to our website http://www.jbckj.cn Consult!
