中科聚峰攪拌機安裝調試步驟你了解嗎？
當我們在中科聚峰攪拌機的安裝工作,調試,是非常重要的一部分必須能夠忽略,如果你不知道如何做之前還是隨著小編先深入了解,在那之后你不需要擔心沒有以正確的方法進行安裝調試。
When we install and debug the mixer in Zhongke, it is a very important part that must be ignored. If you don't know how to do it before or with the editor, you don't need to worry about not installing and debugging in the right way after that.
干粉砂漿包裝機安裝的設計和選擇與攪拌課程的目標密切相關。不同的攪拌工藝需要通過不同的攪拌安裝和操作來完成。在設計選型中，根據攪拌過程的目標和要求確定攪拌器的類型、功率和攪拌速度，然后選擇減速機、機架、攪拌軸和軸封。具體步驟如下:
The design and selection of the installation of the dry mortar packaging machine is closely related to the objectives of the mixing course. Different mixing processes need to be completed by different mixing installation and operation. In the design and selection, the type, power and mixing speed of the mixer are determined according to the objectives and requirements of the mixing process, and then the reducer, frame, mixing shaft and shaft seal are selected. The specific steps are as follows:
1. 根據工藝前提、攪拌目的和要求，選擇攪拌器類型。在選擇攪拌器類型時，要充分掌握攪拌器的動態特性、攪拌器在攪拌過程中的運動規律以及各種攪拌目的之間的因果關系。
1. Select the mixer type according to the process premise, mixing purpose and requirements. When choosing the type of agitator, we should fully grasp the dynamic characteristics of the agitator, the motion law of the agitator in the mixing process and the causal relationship between various mixing purposes.
2. 根據確定攪拌器類型和運動形式的攪拌機在攪拌的過程中,這個過程需要控制的混合時間、沉降速度和分散度,電力,攪拌器的攪拌速度和直徑?jīng)Q定的實現技巧和會計的模仿設計機器。
2. According to the type and movement of the mixer in the process of mixing, this process needs to control the mixing time, settling speed and dispersion, the power, the mixing speed and diameter of the mixer to determine the implementation skills and the accounting simulation design machine.
3.根據電機功率、攪拌速度和工藝條件，從選型表中選擇減速機型號。假設根據實際工作轉矩選擇減速器，實際工作轉矩應小于減速器允許的轉矩。
3. According to the motor power, mixing speed and process conditions, select the reducer model from the selection table. Assuming that the reducer is selected according to the actual working torque, the actual working torque should be less than the allowable torque of the reducer.
4. 根據減速機的輸出軸頭d和攪拌軸系的支承方式，選擇與d型號規格相同的機架和聯軸器。
4. According to the output shaft head D of the reducer and the supporting mode of the mixing shaft system, select the same frame and coupling as the model D.
5. 根據機架攪拌軸頭的do尺寸、設備的密封空間、任務壓力和任務溫度選擇軸封類型。
5. Select the shaft seal type according to the do size of the mixing shaft head of the rack, the sealing space of the equipment, the task pressure and the task temperature.
6. 根據設備模式和施工要求，設計選擇攪拌軸的結構型式，并對其強度和剛度進行校核。
6. According to the equipment mode and construction requirements, design and select the structure type of mixing shaft, and check its strength and rigidity.
7. 根據攪拌軸的機架、齒條類型和壓力等級的正常尺寸DN，選擇設備底蓋、法蘭底座或法蘭。
7. Select equipment bottom cover, flange base or flange according to the frame, rack type and normal size DN of pressure grade of mixing shaft.
8. 根據支架和防振前提，確定設備是否能支撐支架。
8. Determine whether the equipment can support the support according to the support and anti vibration premise.
在上述選擇過程中，可參考干粉砂漿包裝機的攪拌安裝組合及設備。在設備加工過程中，各部件之間連接輪轂的尺寸是軸頭的尺寸。
In the above selection process, you can refer to the mixing installation combination and equipment of the dry mortar packaging machine. In the process of equipment processing, the size of connecting hub between components is the size of shaft head.
以上是中科聚峰攪拌機廠家為大家介紹的相關內容，想要了解更多內容，歡迎訪問網站：http://www.jbckj.cn
The above is the relevant content introduced by Zhongke Jufeng blender manufacturer. To learn more, please visit the website: http://www.jbckj.cn
